Semi Gantry Cranes
Our innovative Semi Gantry Cranes combine the benefits of both gantry and overhead cranes, creating efficient material handling solutions for diverse operational environments. These versatile cranes feature one end supported by a runway system and the other by a freestanding leg, making them ideal for facilities that require both indoor and outdoor lifting capabilities. With their hybrid design, semi gantry cranes offer exceptional flexibility and cost-effectiveness.
Key Specifications
Semi Gantry Crane Overview
Semi Gantry Cranes represent an innovative hybrid solution that combines the structural support of overhead cranes with the flexibility of gantry cranes. These versatile material handling systems feature one end running on an elevated runway attached to the building structure, while the other end is supported by a freestanding leg that moves along a ground-level runway. This unique design makes them perfect for facilities that need to bridge between indoor and outdoor areas or navigate around obstacles.
The semi gantry design offers significant advantages over traditional cranes, including reduced installation costs (compared to full gantry cranes), increased flexibility in facility layout, and the ability to service both indoor and outdoor areas with a single crane system. These cranes are particularly valuable in facilities where full overhead crane coverage is not possible or practical.
Detailed Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity Range | 1 to 30 Tons (Custom capacities available) |
| Span | Up to 25 Meters (Adjustable based on requirements) |
| Lifting Height | Up to 18 Meters |
| Work Duty | FEM 1Am to 2m (Light to Medium Duty) |
| Control | Pendant Control / Remote Control / Manual Options |
| Travel Speed | 10-25 m/min (adjustable with VFD options) |
| Power Supply | 220V/415V, 3 Phase, 50Hz (Various options available) |
| Runway Types | Combination of overhead runway and ground track |
Key Features & Benefits
- Hybrid design combining overhead and gantry crane benefits
- Cost-effective solution compared to full gantry cranes
- Ideal for facilities with partial overhead support availability
- Seamless operation between indoor and outdoor areas
- Flexible layout options to navigate around obstacles
- Reduced foundation requirements compared to full gantry cranes
- Customizable span and height to suit specific facility layouts
- Both electric and manual operation options available
- Easy installation with minimal structural modifications
- Safety features including overload protection and limit switches
Industrial Applications
Semi Gantry Cranes are versatile solutions suitable for numerous material handling applications where traditional cranes may not be practical:
- Manufacturing facilities with partial overhead support structures
- Warehouses requiring access to both indoor and outdoor areas
- Loading bays and dock areas that bridge inside and outside spaces
- Maintenance shops with limited overhead clearance areas
- Fabrication facilities needing to work around fixed obstacles
- Assembly areas with mixed infrastructure support capabilities
- Storage yards with partial covering or shelter structures
- Production facilities with evolving layout requirements
